J MODEL
25 mph
Top speed
100%
Street legal compliance
2, 4, and 6
Passenger options
5
J Model standard colors
Simplicity. Style. Performance.
Getting behind the wheel of a brand-new vehicle is always an exciting moment. It’s not just about the sleek design or the shiny exterior it’s the promise of new adventures, smoother drives, and the thrill of exploring the road with a fresh perspective. The J Model is more than just a mode of transportation; it’s a leap forward in technology, comfort, and design.
Sales are currently live in KS, KY, NJ, OK, OR, SC, TN and TX. Please choose a different state or contact us for assistance.
Experience a new star
The J Model electric golf cart is designed for versatility—perfect for solo drives, couples, families, or groups. Whether you’re cruising the neighborhood or hitting the town, the J Model delivers smooth performance and smart features in a sleek, street-ready design.
LITHIUM POWER
STRONG AND STEADY AT ANY CHARGE LEVEL
Boost performance, range and in-vehicle connectivity with STAR’s lithium battery upgrades. Running on top-rated LiFePO4 LFP technologies, STAR-smart batteries take a charge, hold a charge, and recharge 2,000+ times with very low p ower loss.
AMERICAN-BUILT ELECTRIC VEHICLES
At STAR EV’s USA-based warehouse and assembly facility, we engineer and deliver market-leading products that are tailored to our customers’ modern lifestyles.
We offer the highest standards, with the elegant styling, comfortable ride, and low maintenance/high performance that thousands have come to recognize from STAR.
Drive smarter. Ride together.
Go electric with the J Model
from STAR EV.
Standard in every model
Automotive paint and finishing
Safety seatbelts
LED headlights, high and low beam, tailights
Flip seat with storage trunk
Injection molded roof with grab handles
Side mirrors
Aluminum rocker panels
7" display with backup camera
Spandex leather covered seats
STYLE | PERFORMANCE | FUN
FAQs
What batteries does a J Model use?
What is the warranty on the J Model?
How do I clean my golf cart?
Specifications
Dimensions
Overall dimensions
92” x 47” x 69” (2340 x 1200 x 1760 mm)
Wheel base
66” (1670 mm)
Ground Clearance
4” (100 mm)
Wheel Type
12*7
Tire Size
215/35-12
Front wheel tread
37” (930 mm)
rear wheel tread
39” (990 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
2
max speed
19.5 mph, or 25 mph if LSV
climbing grade
30% (full load)
turning radius
3.1 m (10.2 ft)
load range
55 km (34 miles) (full load)
maximum load
340 kGs (750 lbs)
net weight
490 kGs (1080 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
4.5 m (15 ft)
rear end ratio
Gear ratio 12.31
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
Dimensions
Overall dimensions
105” x 47” x 75” (2665 x 1200 x 1900 mm)
Wheel base
66” (1670 mm)
Ground Clearance
4” (100 mm)
Wheel Type
12*7
Tire Size
215/35-12
Front wheel tread
37” (930 mm)
rear wheel tread
39” (990 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
4
max speed
19.5 mph, or 25 mph if LSV
climbing grade
30% (full load)
turning radius
3.1 m (10.2 ft)
load range
55 km (34 miles) (full load)
maximum load
340 kGs (750 lbs)
net weight
490 kGs (1080 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
4.5 m (15 ft)
rear end ratio
Gear ratio 12.31
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
Dimensions
Overall dimensions
115” x 51.2” x 79” (2910 x 1300 x 2000 mm)
Wheel base
66” (1680 mm)
Ground Clearance
6” (150 mm)
Wheel Type
14*7
Tire Size
23*10-14
Front wheel tread
39” (990 mm)
rear wheel tread
41” (1030 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
4
max speed
19.5 mph, or 25 mph if LSV
climbing grade
30% (full load)
turning radius
4 m (13 ft)
load range
50 km (31 miles) (full load)
65 km (40 miles) (no-load)
maximum load
340 kGs (750 lbs)
net weight
540 kGs (1190 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
5m (16 ft)
rear end ratio
Gear ratio 14:1
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
Dimensions
Overall dimensions
120“ x 47” x 75” (3070 x 1200 x 1900 mm)
Wheel base
97” (2460 mm)
Ground Clearance
4” (100 mm)
Wheel Type
12*7
Tire Size
215/35-12
Front wheel tread
37” (930 mm)
rear wheel tread
39” (990 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
4
max speed
19.5 mph, or 25 mph if LSV
climbing grade
25% (full load)
turning radius
4.5 m ( 15ft)
load range
50 km (full load) (31 miles)
maximum load
510 kGs (1124 lbs)
net weight
580 kGs (1279 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
4.5 m (15 ft)
rear end ratio
Gear ratio 12.31
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
Dimensions
Overall dimensions
127” x 49” x 81” (3230 x 1245 x 2050 mm)
Wheel base
97” (2460 mm)
Ground Clearance
6” (150 mm)
Wheel Type
14*7
Tire Size
23*10-14
Front wheel tread
39” (990 mm)
rear wheel tread
41” (1030 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
4
max speed
19.5 mph, or 25 mph if LSV
climbing grade
25% (full load)
turning radius
5m (16 ft)
load range
50 km (full load) 30 miles
65 km (no-load) 40 miles
maximum load
510 kGs (1124 lbs)
net weight
580 kGs ( 1278 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
5m (16 ft)
rear end ratio
Gear ratio 14:1
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
Dimensions
Overall dimensions
134” x 47” x 75” (3400 x 1200 x 1900 mm)
Wheel base
97” (2460 mm)
Ground Clearance
4” (100 mm)
Wheel Type
12*7
Tire Size
215/35-12
Front wheel tread
36” (930 mm)
rear wheel tread
39” (990 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
6
max speed
19.5 mph, or 25 mph if LSV
climbing grade
25% (full load)
turning radius
4.5m (15 ft)
load range
50 km (full load) (31 miles)
maximum load
510 kGs (1124 lbs)
net weight
610 kGs (1345 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
5m (16.4 ft)
rear end ratio
Gear ratio 12.31
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
Dimensions
Overall dimensions
146” x 49” x 81” (3705 x 1245 x 2050 mm)
Wheel base
97” (2460 mm)
Ground Clearance
17.3” (440 mm)
Wheel Type
14*7
Tire Size
23*10-14
Front wheel tread
39” (990 mm)
rear wheel tread
41” (1030 mm)
BODY & CHASSIS
Chassis
Steel
Body
Plastic front and rear body
roof
Plastic, injection molded
ROCKER PANELS
Aluminum
power
Batteries
Marxon 48V105A lithium battery
motor
HSLT AC 48V4KW
controller
MCX 350A controller
charger
Marxon 48V20A charger
Accelerator
Inductance Accelerator (0-5V)
Converter
DC48-12V/30A
performance
passengers
6
max speed
19.5 mph, or 25 mph if LSV
climbing grade
25% (full load)
turning radius
5m (16 ft)
load range
50 km (full load) 30 miles
65 km (no-load) 40 miles
maximum load
510 kGs (1124 lbs)
net weight
620 kGs (1367 lbs)
brake system
Front wheel disc brake & Rear wheel mechanical drum brake with foot parking
braking distance
5m (16 ft)
rear end ratio
Gear ratio 14:1
steering & suspension
steering system
Rack & Pinion Steering
suspension
McPherson coil spring
Specifications are subject to change without notification
